Adapter inner elbows are a type of connector used in piping systems that allows pipes of different diameters or types to be connected to each other through a single female threaded interface. Adapter inner elbows not only provide a change in pipe orientation, but also enables a conversion of pipe size, which is an indispensable component in fluid control and pipe layout.
|
Model |
Inner Diameter |
Outer Diameter |
Connection Type |
Remarks |
|
Type 1 |
16 |
22 |
Glue |
Suitable for small water supply systems |
|
Type 2 |
20 |
27 |
Threaded |
Suitable for household drainage systems |
|
Type 3 |
25 |
32 |
Welded |
Suitable for agricultural irrigation systems |
|
Type 4 |
32 |
40 |
Clamp |
Suitable for industrial cooling systems |
|
Type 5 |
40 |
50 |
Threaded/Glued |
Suitable for large building drainage systems |
|
Type 6 |
50 |
63 |
Welded/Hot-melt |
Suitable for municipal drainage systems |
● Connecting Pipes: Connect two sections of pipes to ensure smooth flow of fluid.
● Change Flow Direction: Guide the fluid to change direction to suit the needs of the pipe layout.
● Fit Size: Connect pipes of different diameters for flexibility in the piping system.
● Material Transitions: Connecting pipes of different materials, such as between metal and plastic.
● Simplified Installation: Provides a convenient way to connect, reducing installation time and costs.
|
Product Specification Customization |
Tailoring the product specifications to meet specific customer requirements, such as size, weight, or composition. |
|
Packaging Customization |
Offering various packaging options, including different materials, sizes, and designs, as well as personalized branding and logo incorporation. |
|
Batch Sizes |
Offering flexibility in order quantities, from small batch production for niche markets to large scale for mass distribution. |
|
Additional Services |
Offering additional services such as assembly, kitting, or value-added processing that can save customers time and resources. |
|
Delivery Scheduling |
Customizing delivery schedules to align with customer needs, including just-in-time delivery or scheduled drop-offs. |
|
Design Element |
Description |
|
Size Specifications |
Including inner diameter, outer diameter, etc., to ensure compatibility with other parts of the piping system |
|
Material Selection |
Such as PVC, ABS, PE, PP, HDPE, etc., chosen based on application scenarios for corrosion resistance, high temperature resistance, or pressure resistance |
|
Connection Type |
Including glue, threaded, welded, clamped, etc., selected according to the needs of the piping system |
|
Fluid Characteristics Consideration |
Designing the elbow structure and material based on fluid properties (e.g., temperature, pressure, corrosion) to ensure safety and durability |
|
Angle Design |
Common angles include 45 degrees, 90 degrees, etc., selected based on piping layout requirements |
|
Wall Thickness |
Designed with appropriate wall thickness based on working pressure and fluid characteristics to ensure structural strength of the elbow |
|
Surface Treatment |
Such as corrosion-resistant coatings, polishing, etc., to improve durability and aesthetics of the elbow |
Send An Inquiry
Q1: What sizes are available?
A: Common pipe diameters are 1/2 inch, 3/4 inch, 1 inch, angle of 45°, 90°, and subdivision according to use.
Q2: What material to choose?
A: PVC for water supply and drainage, stainless steel for hydraulics, and plastic for electrical, according to actual needs.
Q3: Is adapter inner elbow difficult to install?
A: It's not difficult, there is a standard interface, prepare a wrench, and screw it according to the instructions.
Q4: How high temperature can it withstand?
A: About 40°C - 60°C for plastic, 20°C - 80°C for rubber, several hundred °C for stainless steel, see instructions.
